Customising Options

simple and versatile
Widest range of customising options including handles, colours, screening and security options.

Handle Options

Altair® Louvre Handles to suit your situation.
For technical details please visit the Technical page.

Altair Louvre Standard Handle

Standard Handle

Altair Louvre Low Profile Handle

Low Profile Handle

Altair Louvre Innoscreen Handle

Innoscreen Handle

Altair Louvre Ring Handle

Ring Handle

Altair Louvre Standard Handle

Standard Handle

Altair Louvre Low Profile Handle

Low Profile Handle

Altair Louvre Innoscreen Handle

Innoscreen Handle

Altair Louvre Ring Handle

Ring Handle

Handle 3D Models

NOTE: Whenever you see this symbol click on an illustration to view and rotate a 3D interactive version. Viewing may not be possible on some older computers. We recommend Google Chrome for the best viewing results.
Altair Louvre Standard Handle

Standard Handle

Altair Louvre Low Profile Handle

Low Profile Handle

Altair Louvre Innoscreen Handle

Innoscreen Handle

Altair Louvre Ring Handle

Ring Handle

Map Rod

Map Rod used in conjunction with the Ring Pull Handle when installed out of arm’s reach.

  • 2m, 3m and 4m set lengths
  • 1.8m – 3.6m telescopic length
NOTE: Handles positions can be moved from left to right, higher or lower depending on the individual requirement. Please speak to your Customer Service Consultant at the time of order placement.

152mm Louvre Handle Positions

102mm Louvre Handle Positions

Louvre Blade Options

With Altair® Louvre Windows you can choose blades that best suit the windows function, such as maximising views, letting in/reducing sunlight, reducing glare, gaining privacy or creating your own design style.

For technical details please visit the Technical page.

Blade Dimensions

Blade height
Altair Louvre Windows are available with two blade heights: 102mm (4”) and 152mm (6”).

Blade length
The length of the louvre blade is typically based on the bay width required for the window application and any length restrictions to comply with Building Codes. For more information see FAQ “How wide can my louvres be?”.

Blade thickness
The Altair Louvre design has been optimised for 6mm thick glass and 14mm thick timber blades. The use of other thicknesses will compromise the performance of the product and are not warranted by Breezway.

Blades for Stronghold
Blades that are mechanically retained by the Stronghold System are available for use with 6mm thick, 152mm or 102mm drilled glass or aluminium blades. For more information, visit the Stronghold System page.

Blade sizes for Altair Louvres
Blade heights of 102mm (4”) and 152mm (6”) available.

Blade Material

Altair Louvre Glass Blades

Glass Blades

Altair Louvre Timber Blades

Timber Blades

View our Timber Blade and Frame page for more information.
Altair Louvre Aluminium Blades

Aluminium Blades

Benefits Summary

Key consideration

Blade type

Comments

Increased glass safetyToughened Glass
Toughened glass is around 5 times stronger than un-toughened glass. Not only is it harder to break, but if it does break, it breaks into small fragments with square edges instead of razor-sharp shards of glass. Building codes will require toughened glass in certain situations in the building. Toughening all glass blades is an extra precaution that is available.
Timber and AluminiumTimber and aluminium obviously do not shatter at all.
Clear views and maximum daylightClear GlassClear glass will maximise these considerations. Tinted glass can also be very effective with only slight reductions in daylight.
Increased insulationClear low e Glass and Timber
Clear glass with a low emissivity coating and timber have insulating properties to reduce the heat transfer through the blade.
Protection from heat gain due to direct sunlightGlass – tinted grey or green
Reduces the Solar Heat Gain when protection from direct sunlight is wanted. This will typically be a key consideration on western elevations (as windows facing the west are exposed to hot afternoon sun).
Timber and AluminiumTimber and aluminium are solid blades and very effective in this role.
Heat gain from direct sunlight is desirableClear GlassIn colder seasons heat gain from sunlight is a very desirable benefit. North facing windows will typically be clear glass to get this free heating benefit from nature.
PrivacyGlass – satinlite or satina
These glasses are obscure to provide privacy while also letting in daylight while closed.
Aluminium and TimberAluminium and timber are solid blades that will provide complete privacy while closed, but need to be open to provide daylight.
Colour, visual impactAluminiumAluminium blades can be anodised or powder coated to a wide array of colours.
Timber warmth or lookTimber
Our Western Red Cedar blades provide the timber “look” and the insulated benefits of timber.
Aluminium – Decowood Aluminium blades can be finished with Decowood timber look powdercoat. This provides the appearance of timber, with the low maintenance of aluminium.

Restricted Blade Openings

Due to compliance laws you may need to restrict your louvre openings to meet state or local government regulations. There are a number of reasons why you may need restricted openings including situations when using louvres for fall prevention, louvres adjacent to swimming pools etc. To find out more please visit our Compliance page or download our design manual from the Downloads page.

Fixed Louvres

For technical details please visit the Technical page.

  • Not available with 102mm clip.
  • As outlined in Clause F1.13(c)(iii) of the NCC, fixed louvres are exempt from compliance with AS2047.
  • Fixed louvres are only available in standard heights.
  • Louvres blades are fixed at a 45 degree angle.

Applications for Fixed Vent Louvres

Use fixed vent louvres where permanent ventilation, light, privacy and a degree of weatherproofing is required. Some typical applications include:

  • Vented roofs
  • Laundries (industrial, domestic)
  • Bathrooms
  • Public Amenities
  • Housing for air conditioning units
  • Screening walkways
No. of BladesHeight (mm) Height (mm)
No WeatherstripWith Weatherstrip
3310320
4400410
5490500
6580590
7670680
8760770
9850860
10940950
1110301040
1211201130
1312101220
1413001310
1513901400
1614801490
1715701580
1816601670
1917501760
2018401850
2119301940
2220202030
2321102120
2422002210
2522902300
2623802390
2724702480
2825602570
2926502660
3027402750
3128302840
3229202930
3330103020

Altair® Louvre Window Sizes

Altair Louvre Windows are custom manufactured to order, meaning there is a wide flexibility in sizes available. There are no standard blade widths, most louvres bays are between 600mm and 900mm but can extend up to 1200mm if using the Stronghold System. For technical details please visit the Technical page.

Heights

  • Standard heights are based off the chosen blade height of 102mm and 152mm. *Recommended Option*
  • Off Standard heights are available but will add cost to your window and result in a fixed louvre blade to act as a filler piece.
  • The type of window frame chosen will affect the standard heights.

Widths

  • There are no standard louvre blade or louvre bay widths.
  • When determining the bay widths possible a rule of thumb is the higher the wind and water performance required, the shorter the blade should be (i.e. cyclonic regions).
  • Most blade lengths are between 600mm to 900mm wide, or up to 1200mm if using the Stronghold System.
  • Multiple louvre bays can often achieve the desired frame width.
  • Breezway’s framing systems can offer a maximum of 4 metres wide.
Please note: For Powerlouvre Windows, the minimum bay widths are:
  • 2-9 blade high Powerlouvres = 400mm
  • 10-18 blade high Powerlouvres = 500mm
Please speak to your local window manufacturer for advice on your specific circumstances.
Altair Louvre Fixed Blade

Altair® Louvre Standard Heights

No. of BladesAltair Louvres in Easyscreen Window System

Standard Heights

Altair Louvres in Innoscreen Window System

Standard Heights

Altair Louvres in SL2 Window System

Standard Heights

Altair Louvres for Other Frames with Breezway Weatherstrip

Standard Heights*

Altair Dualair Secondary Glazed Louvre Component System

Standard Heights

152 mm Blade102 mm Blade152 mm Blade102 mm Blade152 mm Blade102 mm Blade152 mm Blade102 mm Blade152mm1 Blade152mm2 Blade
2371mm-380mm-358mm-330mm-418mm423mm
3511mm361mm520mm370mm498mm348mm470mm320mm558mm563mm
4651mm451mm660mm460mm638mm438mm610mm410mm698mm703mm
5791mm541mm800mm550mm778mm528mm750mm500mm838mm843mm
6931mm631mm940mm640mm918mm618mm890mm590mm978mm983mm
71071mm721mm1080mm730mm1058mm708mm1030mm680mm1118mm1123mm
81211mm811mm1220mm820mm1198mm798mm1170mm770mm1258mm1263mm
91351mm901mm1360mm910mm1338mm888mm1310mm860mm1398mm1403mm
101491mm991mm1500mm1000mm1478mm978mm1450mm950mm1538mm1543mm
111631mm1081mm1640mm1090mm1618mm1068mm1590mm1040mm1678mm1683mm
121771mm1171mm1780mm1180mm1758mm1158mm1730mm1130mm1818mm1823mm
131911mm1261mm1920mm1270mm1898mm1248mm1870mm1220mm1958mm1963mm
142051mm1351mm2060mm1360mm2038mm1338mm2010mm1310mm2098mm2103mm
152191mm1441mm2200mm1450mm2178mm1428mm2150mm1400mm2238mm2243mm
162331mm1531mm2340mm1540mm2318mm1518mm2290mm1490mm2378mm2383mm
172471mm1621mm2480mm1630mm2458mm1608mm2430mm1580mm2518mm2523mm
182611mm1711mm2620mm1720mm2598mm1698mm2570mm1670mm2658mm2663mm
192751mm1801mm2760mm1810mm2738mm1788mm2710mm1760mm--
202891mm1891mm2900mm1900mm2878mm1878mm2850mm1850mm--
213031mm1981mm3040mm1990mm3018mm1968mm2990mm1940mm--
22-2071mm2080mm-2058mm-2030mm--
23-2161mm2170mm-2148mm-2120mm--
24-2251mm2260mm-2238mm-2210mm--
25-2341mm2350mm-2328mm-2300mm--
26-2431mm2440mm-2418mm-2390mm--
27-2521mm2530mm-2508mm-2480mm--
28-2611mm2620mm-2598mm-2570mm--
29-2701mm2710mm-2688mm-2660mm--
30-2791mm2800mm-2778mm-2750mm--
31-2881mm2890mm-2868mm-2840mm--
32-2971mm2980mm-2958mm-2930mm--
33-3061mm3070mm-3048mm-3020mm--
* To calculate the gallery height only, deduct 10mm. 1. Dualair Head: Alspec McArthur EVO. Dualair Sill/Transom: Alspec McArthur EVO 2. Dualair Head: Alspec McArthur EVO. Dualair Sill/Transom: Alspec Hunter EVO Acoustic For information on off-standard heights, please refer to the Compare Frames page to locate the Breezway Window System or Componentry of interest. For more information please visit the Dualair System page.

Keylocks, Screens and Security Bars

Altair® Louvres offer a wide variety of barrier options to choose from.
For technical details please visit the Technical page.

Altair Louvre Keylock

Keylocks

The Altair Louvre Keylock is strong and durable with an easy to use locking mechanism.
  • Brushed Chrome finish.
  • No maintenance required.
  • Fits most frames and is installed on the opposite side of the handle.
  • Same key can be used to lock or unlock multiple keylocks.
For details on how to operate please view the Keylock Instructions Document.
Altair Louvre Screens

Screens

There are many window framing systems today that will allow a security or insect screen to be placed to the inside or outside of your Altair Louvre Windows.

  • Screens can improve the insulation and shading properties of the louvre window.
  • Breezway offers two framing systems with integrated housing for screens.
  • Altair Components can be installed into other window manufacturer’s frames with screening capabilities.
  • View screen deductions for your Easyscreen Window System or Innoscreen Window System.
  • Visit our Where To Buy page to find your closest window manufacturer.
Altair Louvre Security Bars

Security Bars

Security bars are an effective barrier when the louvre is open, that unlike screens do not reduce any air flow.

  • Available to fit 152mm blade heights.
  • Can suit various frames types.
  • Optional 16mm D bar provides neat finish with no visible louvre and jamb fixings.
  • U channel system functions as an add on to the Altair Louvre System.
  • View the Compare Frames page for more information.

Colours & Finish Selection

Breezway offers an extensive range of colours and finishes, many with optional colour matched handles and clips. For technical details please visit the Technical page.

Selecting the Right Aluminium Finish

Altair Louvre windows are available in three different surface finishes: 25 micron anodised, standard powder coating and high performance powder coating under warranty from Dulux and Akzo Nobel.

Over time, weathering of powder coated surfaces should be expected, resulting in a gradual change in appearance. Selecting the right powder for the atmospheric conditions of the site and correct maintenance will be critical to the ongoing appearance of the finish.

The application of high durability powder will reduce this deterioration and is essential for severe industrial, coastal or tropical environments.

Note: Industry accepted colour variation can occur during the aluminium anodising process.

ProductFilm Integrity WarrantyColour IntegrityRecommended End Use
Interpon D1000 Dulux Duralloy10 years7 yearsResidential and Light Commercial to 3 Levels; and more than 100 metres from any salt water or surf line
Interpon D2525 25 years15 yearsCommercial Prominent and Coastal
Dulux Duratec25 years20 yearsCommercial Prominent and Coastal
Clear anodised 25 µm10 years10 yearsSuitable for all environments including; severe, industrial, coastal or tropical environments

Note: All Dulux Duratec Warranties applied for on orders prior to 2nd September 2019 only carry a 15 year colour integrity warranty as per the warranty period offered by Dulux. For more information please visit www.duluxpowders.com.au.

Powder Coated Aluminium Window Colour Chart

These colours are available with optional colour matched handles and clips. Some colour variation between aluminium and plastic can occur.
Our Standard Colour Range is listed below or view our Standard Colour Brochure. Please contact Breezway if you require a hard copy or to learn more about Off Standard finishes.

To learn more about how to care for your aluminium finishes, please visit the Care & Maintenance page.
NOTE: These colours are indicative only and may not exactly reflect their true colour due to differences in screen calibration.

Anodic Bronze Satin GY114A

Anodic Natural Matt GY235A

Anodic Off White Matt GD227A

Anodised (Clear) 25 Micron

Anotec Silver Grey Matt 27251272

Anotec Dark Grey Matt 27251275

Architectural White 91133711

APO Grey Satin GL107A or 27232786 or 26032786

Black Satin GN150A or 27219268

Custom Black Matt GN248A

Charcoal Gloss GL035A

Charcoal Metallic Gloss GM019A

Deep Ocean Matt GJ203A

Deep Ocean Satin 2725125S or 2605125S

Dune Satin 2723087S or 2603087S

Hammersley Brown Satin GM100A or 27284657 or 26084657

Monument Matt GL229A

Notre Dame Gloss GL040A or 27236672 or 26036672

Pearl White Gloss GA078A or 2721114G

Pottery Satin GM175A

Primrose Gloss GD037A or 27284365 or 26084365

Silver Kinetic Pearl Satin 9717043K

Stone Beige Matt GD247A or 27232538 or 26032538

Surfmist Matt 2603067M

Surfmist Satin 2601137S

Ultra Silver Gloss GY070A

White Birch Gloss GA057A or 27237131

Woodland Grey Matt GL205A

Woodland Grey Matt 95951698

Woodland Grey Satin GP105A

Woodland Grey Satin 2727255S

Anodic Bronze Satin GY114A
APO Grey Satin GL107A or 27232786 or 26032786
Deep Ocean Matt GJ203A
Pearl White Gloss GA078A or 2721114G
Surfmist Satin 2601137S
Woodland Grey Satin 2727255S
Anodic Natural Matt GY235A
Architectural White 91133711
Deep Ocean Satin 2725125S or 2605125S
Pottery Satin GM175A
Ultra Silver Gloss GY070A
Anodic Off White Matt GD227A
Black Satin GN150A or 27219268
Dune Satin 2723087S or 2603087S
Primrose Gloss GD037A or 27284365 or 26084365
White Birch Gloss GA057A or 27237131
Anodised (Clear) 25 Micron
Custom Black Matt GN248A
Hammersley Brown Satin GM100A or 27284657 or 26084657
Silver Kinetic Pearl Satin 9717043K
Woodland Grey Matt GL205A
Anotec Silver Grey Matt 27251272
Charcoal Gloss GL035A
Monument Matt GL229A
Stone Beige Matt GD247A or 27232538 or 26032538
Woodland Grey Matt 95951698
Anotec Dark Grey Matt 27251275
Charcoal Metallic Gloss GM019A
Notre Dame Gloss GL040A or 27236672 or 26036672
Surfmist Matt 2603067M
Woodland Grey Satin GP105A

Standard Australian Finishes Colour & Clip Offer

Note:
  • Clear anodised 25 micron gallery and Weatherstrip material is kept in stock. Other anodised products are subject to a longer lead time.
  • Standard and Secondary colours will be reviewed and adjusted on a six monthly basis subject to market trends and customer usage.
  • Paint codes are to be stated on all orders.
  • Breezway can apply Interpon D1000 and Dulux Duralloy powdercoatings. Warranty information available from www.specifyinterpon.com and www.duluxpowders.com.au
* Complement colour to Bluescope Steel’s COLOURBOND colour range. Selected finishes of identical colour and gloss levels may be used interchangeably. A handle and clip colour matched to the DecoWood Western Red Cedar high performance powder coating is available.
FinishAkzo CodeDulux CodeHandle & Clips at Standard PriceHandle & Clips Colour Matched at Off Standard Price*
Anodic Bronze SatinGY114ABlackYes
Anodic Natural MattGY235ABlackYes
Anodic Off White MattGD227ABlackYes
Anodised (Clear) 25 MicronNatural Grey
Anotec Dark Grey Matt27251275BlackYes
Anotec Silver Grey Matt27251272BlackYes
APO Grey SatinGL107A27232786 / 26032786BlackYes
Architectural White91133711White
Black Satin*GN150A27219268Black
Charcoal Gloss*GL035ABlackYes
Charcoal Metallic GlossGM019ABlackYes
Custom Black Matt*GN248ABlack
Deep Ocean Matt*GJ203ABlackYes
Deep Ocean Satin*2725125S / 2605125SBlackYes
Dune Satin*2723087S / 2603087SBlackYes
Hammersley Brown SatinGM100A27284657 / 26084657BlackYes
Monument Matt*GL229ABlackYes
Notre Dame GlossGL040A27236672 / 26036672BlackYes
Pearl White GlossGA078A2721114GWhite
Pottery SatinGM175ABlackYes
Primrose GlossGD037A27284365 / 26084365BlackYes
Silver Kinetic Pearl Satin9717043KBlackYes
Stone Beige MattGD247A27232538 / 26032538BlackYes
Surfmist Matt* 2603167MBlackYes
Surfmist Satin*2601137SBlackYes
Ultra Silver GlossGY070ABlackYes
White Birch GlossGA057A27237131BlackYes
Woodland Grey Matt*GL205ABlackYes
Woodland Grey Matt*95951698BlackYes
Woodland Grey Satin*GP105ABlackYes
Woodland Grey Satin*2727255SBlackYes
